| Key Specifications | 1. DW75CNC-2A-1S 2. DW75CNC-3A-2S | Notes | |
| maximum bending diameter × wall thickness | Φ75mm × 4mm | 1. Minimum bending radius according to pipe diameter 2. Maximum bending radius according to customer requirements 3. Maximum core length of wear based on customer requirements | |
| maximum bending radius | R250mm | ||
| minimum bend radius | R30mm | ||
| maximum bending angle | 190 ° | ||
| maximum feed length | 2850mm | ||
| Feeding | direct- pinch | ||
| pace of work | bending speed | Max 40 ° /s | |
| Rotary speed | Max 160 ° /s | ||
| feeding rate | Max 800mm /s | ||
| working precision | bending precision | ± 0.1 ° | |
| Rotary precision | ± 0.1 ° | ||
| feeding accuracy | ± 0.1mm | ||
| data input | 1. coordinates (X. Y. Z) 2. work value (YB C ) | ||
| bending mode | 1. servo pipe: 1kw (axis above) 2. hydraulic pipe | ||
| Rotary servo motor power | 1.5kw | ||
| feeding servo motor power | 2kw | ||
| elbow pipe to allow the number of | 1. 12 2. 33 | ||
parts store a few | 1. 330 2. 125 | ||
| hydraulic motor power | 11kw | ||
| system pressure | 12 Mpa | ||
| machine size | 4950 x1350 x 1230mm | ||
| Weight | 4500kg | ||
