pipe diameter（Φ）×wall thickness（t）﹝Taking the maximum applicable minimum bending radius R (8D) for carbon steel pipes as an example）(mm)：

Φ426×16.0t

pipe diameter（Φ）×wall thickness（t）﹝Taking the maximum applicable bending radius R (8D) for stainless steel pipes as an example）(mm)：

Φ426×6t

side length×side length×wall thickness（t）（Taking the maximum applicable bending radius of carbon steel square tube R (10D) as an example）(mm)：

380×380×12t

Maximum feeding travel（*）：

1000mm

Feeding Speed：

Max.350mm/S

Feeding servo control motor power：

0.75KW

Feeding accuracy：

±1mm

Bending speed：

Max.15°/30S

Bending servo control motor power：

0.75KW

Bending accuracy：

±1.5°

Tube rotation angle：

±0.1°

Minimum bend radiusR（*）：

3400

Minimum bending angle(°)：

130°

Each pipe fitting can have a number of bends（△）：

12

Can set the number of pipe fittings files（△）：

100

Maximum hydraulic pressure(Mpa)：

12

Hydraulic motor power(KW)：

37

Machine weight：(T)：

36～37

Overall sizeL.W.H (M)：

19.5×8.5×3.3

Notes：1、*project can be customized to increase or lengthen according to user needs.

2、△project can expand the controller or memory capacity according to user needs.

3、The material of the pipe is designed with a yield strength of 40kg/mm2。
